Band Gap / Источник опорного напряжения (ИОН)
- Band Gap 1,206V: accuracy +/- 0,5%; PSRR -70dB @ 100kHz; 50uA current consumption; supply voltage 1.8V / 3.3V +/- 10%; -40 ... 125°C
- Band Gap 1,176V: accuracy +/- 1,0%; PSRR -45dB @ 100kHz; 5uA current consumption; 1.8V supply voltage; -40 ... 125°C
- Band Gap 1,25V and 2,50V: high accuracy; low power; function on / off; supply voltage 3.3-5.0V; temperature -40...+125°C
- HV BCD Band Gap 1,2V: supply 12V/ 24V/ up to 60V; high electrical performance
- Band Gap 1,206V: high accuracy +/- 0.5%; TC ≤ 10ppm; PSRR -70dB DC; wide supply voltage range 1.55...5.5V; temperature range -40 ... 125°C
- Band Gap 1,176V: accuracy +/- 1,0%; PSRR -45dB @ 100kHz; 5uA current consumption; 1.8V supply voltage; -40 ... 125°C
- Band Gap 1,25V and 2,50V: high accuracy; low power; function on / off; supply voltage 3.3-5.0V; temperature -40...+125°C
- HV BCD Band Gap 1,2V: supply 12V/ 24V/ up to 60V; high electrical performance
- Band Gap 1,206V: high accuracy +/- 0.5%; TC ≤ 10ppm; PSRR -70dB DC; wide supply voltage range 1.55...5.5V; temperature range -40 ... 125°C
Voltage regulators / Регулятор напряжения
- CMOS ULP Capless LDO voltage regulator: vin 1.45V...5.5V; vout 1.2V/ 1.8V; ultra low power, power down mode; high electrical performance; battery supply & smart card application
- BCD HV Switching regulator with 5A output current: 40V input voltage; soft start; Over-Voltage & Short-Circuit protection; Temperature monitor; Current limit
- CMOS linear regulator without external component: output voltage 1.8V +/- 2%; current load up to 50mA; PSRR -65dB @ 100kHz, wide input voltage range up to 1.6... 5.5V; current limit; temperature monitor; function on / off; temperature range -40 ... 125°C
- BiCMOS linear regulator 5V -> 3.3V / 1.8V / 1.2V, accuracy +/- 1%; current load up to 250mA / 500mA ; PSRR -80dB @ 100kHz; functions of current limit and temperature protection; function on / off; low power consumption; temperature -40 ... 125°C
- Linear regulator without external components, output voltage of 1.8V +/- 2%; current load up to 10mA; consumption ≤ 25uA; PSRR -45dB @ 100kHz; supply voltage 3.3V; temperature -40 ... 125°C
- BiCMOS LDO regulator 5V -> 3.3V / 1.8V / 1.2V: accuracy +/- 1%; current load up to 250mA; PSRR -80dB @ 100kHz;functions of current limit and temperature protection; function on / off; low consumption; temperature range -40 ... 125°C
- HV BCD LDO voltage regulator with ultra low dropout voltage; input voltage 2.7...12V/ 24V; output voltage 3.3V/ 5V; output current 125mA/ 250mA / 500mA; good immunity of ESD &EMC; functions current limit and temperature protection; temperature range of -40 ... + 125°C
- BCD HV Switching regulator with 5A output current: 40V input voltage; soft start; Over-Voltage & Short-Circuit protection; Temperature monitor; Current limit
- CMOS linear regulator without external component: output voltage 1.8V +/- 2%; current load up to 50mA; PSRR -65dB @ 100kHz, wide input voltage range up to 1.6... 5.5V; current limit; temperature monitor; function on / off; temperature range -40 ... 125°C
- BiCMOS linear regulator 5V -> 3.3V / 1.8V / 1.2V, accuracy +/- 1%; current load up to 250mA / 500mA ; PSRR -80dB @ 100kHz; functions of current limit and temperature protection; function on / off; low power consumption; temperature -40 ... 125°C
- Linear regulator without external components, output voltage of 1.8V +/- 2%; current load up to 10mA; consumption ≤ 25uA; PSRR -45dB @ 100kHz; supply voltage 3.3V; temperature -40 ... 125°C
- BiCMOS LDO regulator 5V -> 3.3V / 1.8V / 1.2V: accuracy +/- 1%; current load up to 250mA; PSRR -80dB @ 100kHz;functions of current limit and temperature protection; function on / off; low consumption; temperature range -40 ... 125°C
- HV BCD LDO voltage regulator with ultra low dropout voltage; input voltage 2.7...12V/ 24V; output voltage 3.3V/ 5V; output current 125mA/ 250mA / 500mA; good immunity of ESD &EMC; functions current limit and temperature protection; temperature range of -40 ... + 125°C
Frequency OSC / Частотные генераторы
- CMOS 32,768kHz RC oscillator without external components: accuracy 0.5% PVT; current consumption ≤ 0.5uA; supply 0.9V ... 2.2V; trimming, enable; temperature -40 ... 125°C
- CMOS RC oscillator 140kHz/ 512KHz/ 1MHz: low power; supply 0.9V/ 1.2V/1.8V; enable; temperature -40 ... 85°C
- Programmable RC oscillator: 1kHz - 140kHz / 512kHz; accuracy of 1%; low current consumption; supply voltage 1.4 ... 2.2V; enable; temperature range -40 ... 125°C
- CMOS 8MHz RC oscillator: 1% accuracy; supply voltage 1.6 ... 2.2V; -40 ... 125°C; trimming; function on / off
- HV CMOS RC osc 16MHz: supply 2.5/ 5V/ 12V/ 24V; enable; OTP/ Fuse; temperature -40 ... + 125°C
- BiCMOS high frequency 32MHz RC-oscillator: high accuracy 1.0%; duty cycle 50%; low power consumption; supply 1.2V; trimming; enable; temperature -40 ... + 125°C
- CMOS RC oscillator 140kHz/ 512KHz/ 1MHz: low power; supply 0.9V/ 1.2V/1.8V; enable; temperature -40 ... 85°C
- Programmable RC oscillator: 1kHz - 140kHz / 512kHz; accuracy of 1%; low current consumption; supply voltage 1.4 ... 2.2V; enable; temperature range -40 ... 125°C
- CMOS 8MHz RC oscillator: 1% accuracy; supply voltage 1.6 ... 2.2V; -40 ... 125°C; trimming; function on / off
- HV CMOS RC osc 16MHz: supply 2.5/ 5V/ 12V/ 24V; enable; OTP/ Fuse; temperature -40 ... + 125°C
- BiCMOS high frequency 32MHz RC-oscillator: high accuracy 1.0%; duty cycle 50%; low power consumption; supply 1.2V; trimming; enable; temperature -40 ... + 125°C
Phase-locked loop / Фазовая автоподстройка частоты (ФАПЧ)
- CMOS 40nm 80...600 MHz PLL: supply 0.9V; duty 50%; divider 4+3 bits; super low power; area 285x460 um with filter; power down mode; temperature -40... + 125°C
- CMOS PLL 90… 520MHz: supply core 0.9V/ 1.2V/ 1.8V +/- 10%; low power; small area 125x125um; temperature -40...+125°C
- CMOS PLL 75 ... 450MHz, 1.8V supply; low phase noise Jrms 1ps; duty cycle - 50%; temperature -40 ... + 125°C; function on / off
- PLL 48MHz: 1,6 ... 2,2V power supply; small area; low current consumption ~ 350uA; temperature range of -40 ... + 125°C
- PLL 50 ... 500MHz; supply voltage of 1.0 ... 1.2 V; phase noise -125dBc/Hz@1MHz; low power consumption mode; fast start & lock; trimming; function on / off; temperature range -40 ... + 125°C
- PLL RF BiCMOS 450 ... 1500MHz, 1.0V supply voltage; ultra low phase noise; trimming, extended temperature range 750 ... 500 MHz RF generator with digital control; 8-bit control; voltage supply 3.3 V; temperature range -40 ... + 85°C
- CMOS PLL 90… 520MHz: supply core 0.9V/ 1.2V/ 1.8V +/- 10%; low power; small area 125x125um; temperature -40...+125°C
- CMOS PLL 75 ... 450MHz, 1.8V supply; low phase noise Jrms 1ps; duty cycle - 50%; temperature -40 ... + 125°C; function on / off
- PLL 48MHz: 1,6 ... 2,2V power supply; small area; low current consumption ~ 350uA; temperature range of -40 ... + 125°C
- PLL 50 ... 500MHz; supply voltage of 1.0 ... 1.2 V; phase noise -125dBc/Hz@1MHz; low power consumption mode; fast start & lock; trimming; function on / off; temperature range -40 ... + 125°C
- PLL RF BiCMOS 450 ... 1500MHz, 1.0V supply voltage; ultra low phase noise; trimming, extended temperature range 750 ... 500 MHz RF generator with digital control; 8-bit control; voltage supply 3.3 V; temperature range -40 ... + 85°C
LVDS TX/RX / Интерфейсы
- LVDS transmitter D2D: speed up to 400Mbps/ 600Mbps; current consumption of less than 5 mA; temperature range -40 ... + 85°C
- LVDS transceiver C2D / D2C: data rate 1.6Gbps; 3.3V supply voltage; consumption ≤35mW; jitter 50ps; temperature range -40 ... + 100°C
- LVDS transceiver C2D / D2C: data rate 1.6Gbps; 3.3V supply voltage; consumption ≤35mW; jitter 50ps; temperature range -40 ... + 100°C
ADC DAC / АЦП и ЦАП
- CMOS 10-bit SAR ADC 1Msps; supply voltage 1.0V / 1.8V; current consumption 150uA; small area; temperature -40... +85°C
- 12bit SAR ADC 500ksps: 1.8V supply voltage; low consumption ≤ 100uA; DNL +/-0.5 LSB; INL +/-1 LSB; small area; temperature range of -40 ... + 125°C
- CMOS 12-Bit 50Msps ADC: supply 5V; current consumption 40mA; temperature range -40... + 105°C
- CMOS 12-bit DAC: 10MHz; number of inputs 2-4 of the channel; current output; 3.3V supply voltage; low consumption; temperature range -40…+125°C
- BiCMOS 12-bit ADC 100MHz; supply 1.2V /3.3V; low power; DNL/INL - +/-0.5LSB / +/-2LSB; temperature -40...125°C
- 12bit SAR ADC 500ksps: 1.8V supply voltage; low consumption ≤ 100uA; DNL +/-0.5 LSB; INL +/-1 LSB; small area; temperature range of -40 ... + 125°C
- CMOS 12-Bit 50Msps ADC: supply 5V; current consumption 40mA; temperature range -40... + 105°C
- CMOS 12-bit DAC: 10MHz; number of inputs 2-4 of the channel; current output; 3.3V supply voltage; low consumption; temperature range -40…+125°C
- BiCMOS 12-bit ADC 100MHz; supply 1.2V /3.3V; low power; DNL/INL - +/-0.5LSB / +/-2LSB; temperature -40...125°C
